Accessories for light tunnels

Accessories for light tunnels

Flashings for light tunnels

SLS flashing

The SLS flashing is designed for use with roofing materials with a thickness of up to 10mm (2 layers, 5mm each, e.g. roofing paper, bituminous shingles and slate.



SLS flashing

SLZ flashing

The SLZ flashing intended for high profile roofing materials with a profile depth of up to 45mm, e.g. tiles, profiled sheet metal.



SLZ flashing



 SLH flashing

The SLH flashing for roofing materials with a profile depth of up to 90mm: tile, high profile sheet metal.

 SLH flashing

Find a Stockist

Flat Roof System SLP i SFP



The flat roof light tunnel system SLP i SFP is used where there is no possibility of using standard vertical or roof windows. The specially designed light tunnels consists of an insulation base SFP and SLP flashing. The base is made of galvanized steel and insulated with Styrofoam from the inside.SFP







SFP





SLP

SLP



Accessories for light tunnels



SLO light kit

The SLO light kit is used as an alternative source of light in the room after dark. Installed inside the light tunnel.





SLO light kit

The SLM extension kit for flexible reflective tubing

The kit consists of: connecting ring, 120cm section of reflective tube, installation tape. It is possible to order other lengths of reflective tubing which are multiples of 30cm (e.g. 60cm, 90cm, 150cm).



The SLM extension kit for flexible reflective tubing

Extension element for SRM rigid tubing

Extension element for SRM rigid tubing, 61cm in length.



Extension element for SRM rigid tubing

SRK elbow

The SRK elbow changes the angle of reflective tubing within the range of 0 – 65°. For SRT 550 light tunnel, it is available as an option.



SRK elbow

SLC suspender

The SLC suspender is used when the total length of flexible tubing is greater than 5m. Suspender are used to take carry the extra weight of the tubing to prevent any possible separation from the light tunnel flashing.



SRC suspender

The SRC suspender is used when the total length of rigid tubing exceeds 4m.
