Electric awning blind AMZ

Electric awning blind AMZ

Electric awning blind is an appropriate combination of effective protection from heat and comfort of use. Due to the fact that the awning blind absorbs solar radiation before it reaches the glazing and emits the heat to the outside of the room, it constitutes much better protectction from tiresome heat in the sunny days than internal accessories. At the same time, it allows the ingress of natural light and ensures visual contact with the environment.  What’s more... placing the awning blind outside the window does not reduce window viewing area.



The awning blind ensures up to 8 times more effective protection against overheating when compared with internal blinds.

  • AMZ Z-Wave


    AMZ Z-Wave   system, controlled by wall switch or remote control, powered by 15V DC



  • AMZ Solar


    AMZ Solar   awning bling controlled by a remote control



Description



The electric awning blind is exceptionally easy to use. Once installed, it is simply operated by using either the remote control or control unit. The awning blind can be positioned at any point on the window giving different levels of protection from heat and sunlight. We have two versions which are powered by solar energy or electricity.


The awning blind is available in two version:





  • AMZ Z-Wave electrically controlled by remote control or by wall switch in wireless system Z-Wave. In an emergency, the awning blind can be controlled by service button located on the awning blind. The awning blind is powered by 12VDC. Motor nominal current is 1.4A.
  • AMZ SOLAR powered by solar batteries and controlled by remote control. In emergency cases, awning blind can be controlled by service button located on the awning blind. Solar awning blind is powered with 12VDC battery pack built-in blind’s case.The batteries are recharged by the solar panel. Motor nominal current is 1.4A.



Characteristics

  • Effective reduction of heat from the sun

  • Installed on the outside of the window

  • Protection from excessive brightness, whilst maintaining good overall levels of natural light

  • Protection from harmful uv radiation

  • Protection from harmful light reflection, especially important when working with computers

  • Positioned outside, it does not reduce the glazing surface

  • Effective shading of the interior even when the window is ajar

  • When used in rainy weather, reduces noise of hailstones and rainfall



awning blind

The awning blind is made of durable, weather- resistant fibre glass fabric. The fabric is roller mounted with motor fitted inside an aluminium casing which is installed at the top of the window. In the cloth’s edges, there is a special tape that maintains appropriate fabric tension between the guides and prevents the fabric falling out of the guides. Such fabric and profile joining increases its resistance to wind. This solution withstands wind gusts of up to 120km/h and side wind speed of up to 220km/h.

Available colors and materials

AMZ Z-Wave, AMZ Solar awning blinds are available in two groups:

  • Group I - in four colours (material with 10% relative fabric transparency)
  • Group II - available in two colours (with 1% relative fabric transparency)




  • Effect of relative fabric transparency 10% - awning blind Group I

Effect of relative clearance 10%


  • Effect of relative fabric transparency 1% - awning blind Group II

Effect of relative clearance 1%



Group I

Electric awning blind AMZ I
Electric awning blind AMZ II

Group II

Electric awning blind AMZ II

Instructions
