Awning blind AMZ, AMZ NewLine, AME, AMB

Awning blind AMZ, AMZ NewLine, AME, AMB

Have a rest in shade...

The FAKRO awning blind provides optimum protection from overheating while at the same time providing an external view. It will reflect the sun’s rays before they can reach the glass helping to minimise temperatures, reflective glare and the harmful effects of sunlight.

The awning blind is made of durable, weather- resistant fibre glass fabric. The fabric is roller mounted, spring loaded and fitted inside an aluminium casing which is installed at the top of the window. This enables easy control of the blind and makes it possible to use a wider fabric, thus providing additional protection against ingress of light. The blind is controlled by using a 80cm long rod which also comes supplied. Should you require a longer rod, we can provide the ZSZ rod which is 150cm long.



  • AMZ for centre pivot windows FT, PT and top hung and pivot FPP, PPP windows
  • AMZ NewLine these awnings blinds have a new cartridge, significantly improving the aesthetics of the awning blinds,
  • AME for panoramic windows FE,
  • AMB for combination windows B_ _.



  • AMZ


    AMZ  manually operated or with the use of rod (supplied in package)



  • AMZ NewLine


    AMZ NewLine these awnings blinds have a new cartridge, significantly improving the aesthetics of the awning blinds



Characteristic:

  • Up to 8 times more effective protection against overheating when compared with internal blinds
  • The best protection from tiresome heat
  • Effective shading of the room whilst still allowing some light in
  • Comfortable use – we can cover the window for a whole summer without the need to roll it up and down every day
  • Easy installation – we install the blind from the inside (unscrew four screws and then rescrew them again in the same holes)
  • Protection from harmful UV radiation
  • When used in rainy weather, reduces noise of rain



Control

  • AMZ, AME, AMB manually operated or with the use of rod (supplied in package)
  • AMZ NewLine have a new cartridge, significantly improving the aesthetics of the awning blinds - a flat cassette much closer integrated into the window design. In comparison with the current awning blinds, the NewLine version box is made of extrude aluminum, which significantly improves not only the appearance, but also the rigidity of the awning blind, the installation system was changed as well. The new awning blinds AMZ NewLine are mounted on the sleeves to the hood, and after installation the screws are not visible from the outside



Available colors and materials

 AMZ, AMZ NewLine, AME, awning blinds are available in three groups:

  • Group I - in one colour (material with 10% relative fabric transparency)
  • Group II - available in three colours (with 10% relative fabric transparency)
  • Group III - available in two colours (with 1% relative fabric transparency)



  • Effect of relative fabric transparency 10% - awning blind Group I and II

Effect of relative clearance 10%



  • Effect of relative fabric transparency 1% - awning blind Group III

Effect of relative clearance 1%




Group I

Markizy AMZ, AMZ NewLine, AME, AMB I GRUPA

Group II

Markizy AMZ, AMZ NewLine, AME, AMB II GRUPA

Group III

Markizy AMZ, AMZ NewLine, AME, AMB III GRUPA
