Okna do dachów płaskich

Secure type flat roof windows

Secure type flat roof windows are special version of anti-burglary windows.

Windows have a number of solutions that increase anti-burglary protection of products. Both the type F windows (DMF DU6 Secure, DXF DU6 Secure) as well as the type C ones ( DXC P4 Secure, DMC P4 Secure) meet European 2nd anti-burglary class RC 2 as per EN 1627.

Glazing units in type F windows

The outer reflective glass which reflects solar radiation is toughened, while inner glass is anti-burglary and features P4A class. In case of inner pane cracking, shards of glass do not pose a danger as they remain on the film. Secure type window are characterised by energy-efficient DU6 glazing unit with inner anti-burglary glass P4A class. Heat transfer coefficient for the entire window is U=0.88 W/m2K according to EN 12567-2.

Glazing units in type C windows

Secure type window featuring energy-efficient P4 glazing unit with inner anti-burglary glass P4A class. Heat transfer coefficient for the entire window is U=1.2 W/m2K according to EN 12567-2. The dome can be transparent D_C -C or opaque D_C – M.

Availability

The window comes in the following versions:

  • DMF Secure / DMC Secure – opened manually by means of ZSD control rod (control rod is purchased separately). The window opens up to 30cm.
  • DXF Secure / DXC Secure – non-opening.

Characteristics

  • The frame of the flat roof window is manufactured from multi-chamber PVC profiles filled inside with insulation material. With specially designed shape of the profiles, flat roof windows feature up to 16% greater glazed area when compared to solutions of the competition.
  • The type C flat roof window is intended for roofs with pitches between 0° and 15°, while the type F flat roof window is designed for installation in roofs with pitches between 2° and 15°. Windows can be set in 15cm high XRD base which allows raising the window, hence makes it suitable for mounting in different roofs such as green ones. It is possible to connect up to two XRD bases.
  • The window design allows installation of both internal and external accessories. External awning blind protects the room from overheating, while internal accessories provide protection from intense sunlight and enhance interior design.
  • Warranty: 10 years for windows.
  • DXF DU6 Secure


    non-opening
    • 0,88 W/m²K window U-value 0,5 W/m²K glazing U-value 6H-18-4HT -18-44.4T glazing unit argon inert gas filled panes + external glass toughened + internal glass laminated (safe) one seals
  • DMF DU6 Secure


    manually opened with ZSD rod
    • 0,88 W/m²K window U-value 0,5 W/m²K glazing U-value 6H -18-4HT -20-44.2T glazing unit argon inert gas filled panes + external glass toughened + internal glass laminated (safe) three seals
  • DXC P4 Secure


    non-opening
    • 1,2 W/m²K window U-value 1,1 W/m²K glazing U-value 4H - 14 - 33.2T glazing unit argon inert gas filled panes + external glass toughened + internal glass laminated (safe) two seals
  • DMC P4 Secure


    manually opened with ZSD rod
    • 1,2 W/m²K window U-value 0,5 W/m²K glazing U-value 4H - 14 - 33.2T glazing unit argon inert gas filled panes + external glass toughened + internal glass laminated (safe) three seals
